| Nominal Voltage | 48V |
| Dimensions | 482*420*178 |
| Nominal Capacity | 100Ah | Weight | 48Kg |
| Capacity@20A | 300min | Terminal Type | Connector |
| Energy | 4800Wh | Case material | Steel |
| Resistance | ≤30mΩ | Enclosure Protection | IP20 |
| Efficiency | 99% | Cell Type | Prismatic |
| Self discharge | ≤3.5% Per month | Chemistry | Lifepo4 |
| Maximum Module in parallel | 15 | Configuration | 15S1P |
| Maximum continuous discharging current | 50A | Recommend charge current | 40A |
| Peak discharging current | 150A≤3s | Maximum charge current | 50A |
| BMS discharge current cut-off | 130A±20A | Recommend charge Voltage | 52.5-54V |
| Recommend Low voltage disconnect | 42V | BMS charge voltage cut-off | 54V(3.75±0.1V) |
| Discharge Temperature | -20 to 60 ℃ | Certifications | CE/UN38.3/IEC |
| Charge Temperature | 0 to 45 ℃ | Communication | RS232/RS485/CAN |
| Low Temperature cut-off charge | 0 ℃ （Customized） | Shipping Classification | UN3480,CLASS9 |
| High Temperature cut-off charge | 54℃（Customized） | Warranty | 5 Years |
